TiLite TR
The TiLite TR is a premium titanium rigid-frame manual wheelchair designed for active users seeking responsive handling, efficient propulsion and long-term durability. Its distinctive dual-tube frame combines lightweight performance with excellent rigidity, helping transfer more energy from each push into forward movement.
Dual-tube rigid frame
The TR’s dual-tube frame allows TiLite to use smaller-diameter, thinner-gauge tubing while maintaining frame strength and rigidity.
This construction helps minimise unnecessary weight and frame flex, supporting efficient propulsion, responsive handling and improved manoeuvrability.
Customised TiFit design
The TiLite TR can be built around the user’s individual body measurements and functional requirements. A precision fit helps position the rear wheels, backrest, foot support and seating geometry in relation to the user.
This tailored setup may support:
- Efficient propulsion
- Improved upper-limb access to the handrims
- Postural stability
- Easier transfers
- Responsive wheelchair handling
- Greater comfort during everyday use
Infinite centre-of-gravity adjustment
The TiLite TR provides up to 5 inches of centre-of-gravity adjustment, allowing the wheelchair’s balance and responsiveness to be refined.
Moving the rear wheels forward can create a more responsive setup, while positioning them further rearward can provide additional stability. The final position should be selected according to the user’s mobility skills, posture and clinical requirements.
Updated backrest bracket
The redesigned backrest bracket maintains stability while preserving adjustment. This allows the backrest setup to be tailored without compromising the clean, rigid design of the wheelchair.
The folding backrest also helps create a more compact configuration for transport and storage.
Refined castor components
Machined castor-barrel components and slimmer castor caps give the TiLite TR a polished and contemporary appearance.
These streamlined components contribute to the wheelchair’s clean frame design while supporting accurate front-end alignment and responsive handling.
Redesigned frame bumpers
Updated frame bumpers help protect both the wheelchair frame and objects encountered during transfers, vehicle loading and everyday use.
Their integrated design provides practical protection without interrupting the streamlined appearance of the frame.
| Seat Width | 12″ – 20″ |
| Seat Depth | 12″ – 20″ |
| Frame Material | Titanium |
| Transport Weight | 4.9 kg |
| Chair Width | 12″ |
| Camber | 0°, 2°, 4°, or 6° |
| Front Frame Angle | 70°, 75°, 80°, 85°, or 90° |
| Center Of Gravity Adjustment | 5 ” |
| Front Seat Height Range | 15″ – 21″ |
| Weight Limit | Standard 120 kg / Heavy duty 136 kg |
